1000L Blow Moulding Machine YK120

Specifications for 1000L Blow Moulding Machine YK120 Bow molding machine is suitable to produce various plastic bottles and containers in all shapes. It is widely used for PP,PE,HDPE,ABS,PVC and etc.And we can offer engineer to your country to help you set up the machine.High quality assurance will be provided for you. 1.Siemens 7.7large size touch screen, Siemens PLC 2.Hydraulic components are from YUKEN Japan, pheumatic part is from SMCfrom Japan, 3.With lifting platform and lifting die head 4.Alloy steel die head with plating 5.Automatic center lubrication system 6.Inverter controls the extruder SPECIFICATIONS UNITSYK120D SERIERSMax container capacity L200LNumber of die heads Set1Machine dimension (L*W*H) M6.8×5.0×4.5Total weight Ton23 CLAMPING UNIT Clamping force KN640Platen opening stroke mm2500Platen size mm1350*1850Max mould size (W*H) mm1200*1600Mould thickness mm800-1500 POWER Max drive KW90Total power KW130Fan power for screw KW0.14*3Air pressure Mpa0.7Air consumption M3/min0.9Average energy consumption KW96 EXTRDER UNIT Screw diameter mm120Screw L/D ratio L/D25Plasticizing capacity Kg/hour200Number of heating zone Zone3Extruder heating power KW37Extruder driving power KW90 DIE HEAD Number of heating zone Zone3Power of die heating KW17Max die pin diameter mm800Center distance of double die mmCenter distance of tetra-die mm TRAINNING The Buyer could dispatch their operators to the Sellers factory for training, including machine operation, maintenance & simple repairs; Or against the requests of the Buyer, the Sellers technician could train the Buyers operators in the Buyers factory in the periods of installing & adjusting; The training is free of charge; INSTALLATION & ADJUSTMENT The Seller could dispatch an engineer against the requests of the Buyer to install and adjust the machines for one week in the Buyers factory. The Buyer should make a reservation in advance before delivery of the machines; The Buyer should pay for the engineers visa application cost, round air tickets, food & board before his departure; GUARANTEE The guarantee time is one year after the machines normally works in the Buyers factory, if only the problem is cause due to quality control or any reason by the Seller. We will supply replaced parts free of charge and our engineers will guide you how to solve the problems. Any problem caused due to irregular operation or incorrect maintenance by the Buyer wont be listed in guarantee coverage.
